Rubber Hose Hydro Pressure Test Pump And Hose Mandrel Depoling Machine 1000bar
Details:
1.Power end crankshaft housing is made by the cast iron.it is stronger than the aluminium alloy.
2.Cross head is made by the Babbitt hard alloy.it has a long working life for industrial design.
3.Hydraulic end pump head is made by the hard alloy 40Cr.it can work continuously for cleaning jobs.
4.All hydraulic end is desgined for easy uninstall,so it is easy to fix when the parts broken.
5.For some outdoor use purpose,we can make it driven by the diesel engine or the gasoline engine.
6.It is for industrial cleaning or removing.it is heavy duty.
7.It is easy to fix once the wearing parts are broken
8.The cylinders use the new technology,it avoided the cylinders broken problems.
9.we can make according to customers request of the engine.
10.We can supply the pressure datas print out system.
Rubber Hose Hydro Pressure Test Pump And Hose Mandrel Depoling Machine 1000bar
Characteristics as below:
| MODEL | PRESSURE | WATER FLOW | POWER | Plunger Diameter | STROKE |
| Bar | L/min | KW | mm | mm | |
| LF-256/15 | 150 | 256 | 75 | 55 | 70 |
| LF-195/20 | 200 | 195 | 75 | 48 | 70 |
| LF-164/24 | 240 | 164 | 75 | 44 | 70 |
| LF-135/30 | 300 | 135 | 75 | 40 | 70 |
| LF-110/35 | 350 | 110 | 75 | 36 | 70 |
| LF-98/40 | 400 | 98 | 75 | 34 | 70 |
| LF-87/45 | 450 | 87 | 75 | 32 | 70 |
| LF-76/50 | 500 | 76 | 75 | 30 | 70 |
| LF-66/60 | 600 | 66 | 75 | 28 | 70 |
| LF-57/70 | 700 | 57 | 75 | 26 | 70 |
| LF-50/80 | 800 | 50 | 75 | 24 | 70 |
| LF-40/95 | 950 | 40 | 75 | 22 | 70 |
| LF-34/115 | 1150 | 34 | 75 | 20 | 70 |
Product Description
Rubber Hose Hydro Pressure Test Pump And Hose Mandrel Depoling Machine which is used to test the pressure of objects,the machine with high pressure water jet by means of a power device. It can jet high pressure water jet into the objects like the pipes,valves ,let the objects full of high pressure water jet.to see if the objects water leakage or not when the hydro test pump reach a pressure datas.
Features
This machine is made up of mainly by high pressure reciprocating pump, power units and cleaning accessories etc.
1) High pressure reciprocating pump: the pump is horizontal triplex plunger pump, driven by electric motor, made up of by power end and fluid end.
Applications
The pumps are widely used in oil refinery pipes cleaning, heat exchangers pipes cleaning, ship hull cleaing,oil paitings removing,rust removing,etc.
Meanwhile, our pumps also can be used for the automobile steering tubes,brake pipes,fuel pipes,heat exchangers pipes pressure testing,gas steel bottles explosion pressure testing,all kinds of the tubes pressure explosion testing, and so on.
From customers comments who is using the product Rubber Hose Hydro Pressure Test Pump And Hose Mandrel Depoling Machine 1000bar:
the machines are testing the pipes pressure.
Packings as below :
FAQ
Rubber Hose Hydro Pressure Test Pump And Hose Mandrel Depoling Machine 1000bar:
Q1. What about your brand?
A: we are a 40 years manufacturing factory,and the brand is famous in China and famous in Asia.
Q2. Do you have any MOQ limit for the order?
A: Low MOQ, 1pc.
Q3. How do you ship the goods and how long does it take to arrive?
A: Ship by sea shipping.
Q4. How to proceed an order for the product?
A: Firstly let us know your requirements or application.
Secondly We quote according to your requirements or our suggestions.
Thirdly:we sign a contract
Fourthly We arrange the production.
Q5. Is it OK to print my logo on the product?
A: Yes. Please inform us formally before our production.
Q6: Do you offer guarantee for the products?
A: Yes, we offer 1 year warranty to our products.
Our products are sold all over the world, you can rest assured.
