11500psi Industrial High Pressure Jet Washer Hydro Blaster Hydro Jetting Pump

11500psi Industrial High Pressure Jet Washer Hydro Blaster Hydro Jetting Pump

Thanks for using Lifeng serials high pressure industrial washers. We produced these series washers according to the special conditions of industrial cleaning. We self-design and produce the high quality products by using the advanced technology and processing methods. It is reasonable in structure, easy in operation and is durable in use. It widely used in removing sand, paint, dirty stuff, colloid of castings. It gets a good reputation in sugar-refinery, pharmaceutical factory, cement plant, construction, chemical engineering, petroleum, and shipping.

Product Description

Hydro jetting pump is an equipment which is used to clean the surface of objects,the machine with high pressure water jet by means of a power device. It can peel off the dirt ,wash it away to achieve the purpose of cleaning the surface of objects. Because it uses high-pressure water column to clean dirt, high-pressure cleaning is also recognized as the most scientific, economic and environmentally friendly cleaning method in the world compare to the chemical cleaning.

• The structure:

The main parts are: triplex high pressure reciprocating pump, electric engine, water tank, inlet water hose, and cleaning accessory, electric control cabinet.

• Electric engine: we use 3 phases 4 poles asynchronous motors,and also optional use the model 60HZ different voltage, explosion-proof or frequency electric engine according to the client’s request.
• Electric control cabinet: the main function of it is to start, stop, and the protection of phase failure and over charge. Factory sets for 80% step-down start, in order to reduce the harm of current start-up, since the transformer wire decoupling reserve 65% of wiring end, customers can adjust according to oneself circumstance power

• Triplex high pressure reciprocating pump: It is triplex plunger pump, and the working principle and maintenance please see the operation manual of high pressure pump.
• Water tank: water tank is the device of storing water and filter. There are two filtering clapboards, and it should check for some times. The place of the water must higher than the high pressure pump, in order to exclude the air of inlet pipeline.

4. Cleaning accessory: there are many kinds of cleaning accessory; it should match according to the client’s request. The usual are: high pressure hoses, high pressure pipes, foot control valve, spray guns, etc.

High pressure hoses are the main safe parts of the washer; it must use the supporting products. Before use, it must be checked, and if there are some wearing parts, it should be rechanged. Fixed the joint, in case of loosing.

The high pressure pipes usually in a fixed place, which made from the stainless steel extra high pressure, and installed in a fixed pipe way. When installation, it should match with the limit valve and globe valve, and control box.

Foot control valve is used in the pipelines, containers, rotary kiln of cement plant, sometimes used in as the twin gun switch valve operation. When use the special accessories such as spray boom, rotating nozzle, it should use the foot control valve to realize the control of water jet change. When loose the valve, the water jet.

Spray gun id the washer’s change energy parts, for considering the safety, usually, it is overflow spray guns, that means there is a overflow pipe, when close the spray gun, it overflows, and unloading the high pressure pump.

Features

• This machine is made up of mainly by high pressure reciprocating pump, power units and cleaning accessories etc.



  1) High pressure reciprocating pump: the pump is horizontal triplex plunger pump, driven by electric motor, made up of by power end and fluid end.



• Power end: it is made up of by belt pulley(couplings), crankshaft and connecting rod etc. Electric motor or diesel engine,or gasoline engine driven the crankshaft and reduces its speed, and crank link mechanism will change whirling movement to straight line reciprocating movement.
• Fluid end: it is made up of by plunger set, high pressure cylinder, pump body and water input and output valves etc. High pressure cylinder is fixed on crankcase while connecting rod drives plunger to do reciprocating movements, which make volume in cylinder do cyclical change. When plunger is in-sucking stroke, the volume in cylinder increases, water output valve closes, local vacuum is formed. Working media enter into high pressure cylinder by going against water input valve under high atmospheric pressure. When plunger is in discharging stroke, water input valve closes, and plunger transfer the working media to pump body by water output valve, to pressure regulating valve, finally to high pressure spray gun by high pressure hose.

Applications


The pumps are widely used in oil refinery pipes cleaning, heat exchangers pipes cleaning, ship hull cleaing,oil paitings removing,rust removing,etc.
Meanwhile, our pumps also can be used for the fuel pipelines pressure testing,gas steel bottles explosion pressure testing,all kinds of the tubes pressure explosion testing, and so on.


Details:

1.Power end crankshaft housing is made by the cast iron.it is stronger than the aluminium alloy.
2.Cross head is made by the Babbitt hard alloy.it has a long working life for industrial design.
3.Hydraulic end pump head is made by the hard alloy 40Cr.it can work continuously for cleaning jobs.
4.All hydraulic end is desgined for easy uninstall,so it is easy to fix when the parts broken.
5.For some outdoor use purpose,we can make it driven by the diesel engine or the gasoline engine.
6.It is for industrial cleaning or removing.it is heavy duty.
7.It is easy to fix once the wearing parts are broken

8.it can be used for the cement plant which rotary kiln blocked.using the high pressure water jet to make the block place to go through.

Industrial High Pressure Washers For Cement Plant Use 55KW High Pressure Washing Machine:

Characteristics as below:


Catalogue of 700bar Industrial High Pressure Washers For Cement Plant Use 55KW High Pressure Washing Machine:

As a 40 years manufacturing factory,we have many years all come from all over the world,the below are some of our customers,they are from Australia and so on......


Applications:

it is widely used in ship cleaning,rust removing,concrete removing ,fuel pipeline cleaning in refinery fields,oil tank clean,all kinds of the heat exchangers pipes clean,cment plant kiln......





Comments from customers who is using the products 700bar Industrial High Pressure Washers For Cement Plant Use 55KW High Pressure Washing Machine


Comments from customers:





FAQ

11500psi Industrial High Pressure Jet Washer Pressure Washer Hydro Jet Cleaner

Q1. What is  leading time?
A: We need 30 days to deliver.

Q2.are you a factory or a trading company?
A: we are a 40 years old manufacturing factory which located in Chengdu ,China.

Q3. How do you ship the goods ?
A: Ship by  sea shipping.

Q4. How to proceed an order for the product?
A: Firstly let us know your requirements or application.
Secondly We quote according to your requirements or our suggestions.
Thirdly:we sign a contract
Fourthly We arrange the production.

Q5. Is it OK to print my logo on the product?
A: Yes. Please inform us formally before our production.

Q6: Do you offer guarantee for the products?
A: Yes, we offer 1 years warranty to our products.
